Laboratory Spectrophotometer for water analysis

Model: DR-3900
Brand: Hach, USA
This photometer system is designed to deliver accurate results by supporting the operator with each step he is doing:

Sample preparation: reduced handling steps, precise dosin
Sample analysis: automatic test recognition, expiration date check etc.
Documentation of results: versatile data management, control cards

With your daily routine of water analysis in mind the DR3900 spectrophotometer is optimised for safe processes and meaningful reports. Control-parameters like Ammonium, COD, Phosphate, Nitrogen and many others are easy to perform. The handling of tests and photometer is well designed to avoid any errors in your water analysis.

Get A Quote

Beam Height	10
Data Logger	2000 measured values (Result, Date, Time, Sample ID, User ID)
Dimensions (H x W x D)	151 mm x 350 mm x 255 mm
Display	7″ TFT
Display Resolution	WVGA (800 pix x 480 pix)
Display Size	7 inch (17.8 cm)
Display Type	Colored touch-screen
Enclosure Rating	IP40
Interfaces	USB type A (2), USB type B, Ethernet, RFID module
Light Source	Gas-filled Tungsten (visible)
Operating Conditions	10 – 40 °C (50 – 104 °F), max. 80% relative humidity (non-condensing)
Operating Mode	Transmittance (%), Absorbance and Concentration, Scanning
Optical System	Reference beam, spectral
Photometric Accuracy	5 mAbs @ 0.0 – 0.5 Abs, 1 % at 0.50 – 2.0 Abs
Photometric Linearity	< 0.5 % – 2 Abs
Photometric Linearity 2	≤ 0.01 % at >2 Abs with neutral glass at 546 nm
Photometric Measuring Range	± 3.0 Abs (wavelength range 340 – 900 nm)
Power Requirements (Voltage )	110 – 240 VAC
Power Requirements (Hz)	50/60 Hz
Preprogrammed Methods	> 240
Sample Cell Compatibility Rectangular	10, 50 mm, 1 inch; round: 13 mm, 16 mm, 1 inch
Scanning Speed	> 8 nm/S (in steps of 1 nm)
Source Lamp	Gas-filled Tungsten (visible)
Specific Technology	RFID for easy method update, sample ID and Certificate of Analysis
Spectral Bandwidth	5 nm
Stray Light	< 0.1% T at 340 nm with NaNO2
User Programs	100
Wavelength Accuracy	± 1.5 nm (wavelength range 340 – 900 nm)
Wavelength Calibration	Automatic
Wavelength Range	320 – 1100 nm
Wavelength Reproducibility	± 0.1
Wavelength Resolution	1
Wavelength Selection	Automatic, based on method selection
Weight	4.2 kg (9.3 lbs)

Laboratory Spectrophotometer for water analysis
